Refrigerant air dryers are featured by:
● Patented electric cabinet and frame. The frame body is compact, beautiful and firm, more convenient for installation;
● Cross-current heat exchange + annealing design; no dew in the outlet;
● Three-stage gas-water separator, able to separate 95% water thoroughly;
● Integrated design of condenser and cooler with exquisite appearance and more excellent heat dissipation;
● Dual control of pressure and temperature, more stably controlling the evaporation temperature;
● Electric drainage multi-segment timing function, able to select different drainage time according to requirements and discharge the condensed water reliably;
● Computer panel key film control design, exquisite, stable and easy for operation;
● Full compliance with ISO8573.1 international standard.
Air-cooled High-temperature Refrigeration Dryer Specification Table
|
Model |
FD20 |
FD30 |
FD40 |
FD60 |
FD120 |
FD180 |
FD250 |
FD300 |
FD400 |
FD450 |
FD600 |
FD750 |
FD850 |
|
|
Air Flow |
NM3/min |
1.5 |
2.0 |
2.5 |
4.0 |
6.8 |
11.0 |
14 |
18 |
23 |
30 |
35 |
45 |
55 |
|
SCFM |
53 |
70 |
88.5 |
141 |
240 |
389 |
495 |
637 |
814 |
1062 |
1239 |
1593 |
1925 |
|
|
Gross Power(KW) |
0.8 |
0.8 |
0.9 |
1.08 |
1.3 |
1.9 |
2.5 |
2.8 |
3.6 |
4.0 |
6.5 |
6.5 |
10.5 |
|
|
Power Supply(V) |
1ph 220VAC |
3ph 380VAC(Other Customizable Voltages) |
||||||||||||
|
Air Inlet & Outlet Caliber |
G1" |
G11/2" |
G2" |
G21/2" |
DN90/G31/2" |
DN100 |
DN125 |
|||||||
|
Overall Dimensions |
Height(H) |
700 |
700 |
700 |
1000 |
1000 |
1250 |
1250 |
1400 |
1400 |
1400 |
1800 |
1800 |
2300 |
|
Width(W) |
420 |
420 |
420 |
500 |
500 |
570 |
570 |
630 |
630 |
630 |
800 |
900 |
900 |
|
|
Depth(D) |
740 |
800 |
840 |
880 |
930 |
1050 |
1140 |
1330 |
1360 |
1360 |
1400 |
1550 |
2050 |
|
|
Rough Net Weightkg |
50 |
55 |
60 |
90 |
110 |
166 |
182 |
230 |
280 |
330 |
500 |
550 |
848 |
|
|
Working Condition |
Inlet Temperature |
≤70℃(High Temperature) |
Working Pressure |
6～10kg/cm2 |
||||||||||
|
≤45℃(Normal Temperature) |
Maximum Pressure |
1.0Mpa（10kg/cm2）（Customizable Special Pressure） |
||||||||||||
|
Ambient Temperature |
2～38℃ |
Refrigerant |
R22（R407c、R134acustomizable) |
|||||||||||
|
Dewpoint Temperature |
2～10℃（ Air Pressure 7kg/cm2） |
|||||||||||||
|
1. The rated air flow needs to be revised when exceeding the working temperature or pressure. 2. For other specifications, please consult the company. |
||||||||||||||
